RDS5160 Servo 60 kg RC Digital Servo High Torque Mental Gear 180 270 Degree with U-Shaped Mount Disc for 1/5 RC Car Robotics DIY Projects (270)
Product details
| Management number | 216428625 | Release Date | 2026/04/19 | List Price | $13.99 | Model Number | 216428625 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Applicable environmental conditions Storage temperature range: -30°C ~ 80°C. Operating temperature range: -15°C ~ 70°C. Operating voltage range: 6-8.4 V. Mechanical specification: Size: 65 x 30 x 48 mm. Weight: 163 g. Transmission ratio: 279. Bearing: double bearing Connecting wire: 300 ± 5 mm. Motor: 3-Ploe(s). Electrical specification: No-load current (in standstill): 4 mA at (6 V) 5 mA at (7.4 V) 6 mA at (8.4 V). Operating speed (without load): 0.17 sec/60 ° at (6 V) 0.15 sec/60 ° at (7.4 V) 0.13 sec/60 ° at (8.4 V). Stop torque (when blocked): 58 kg. cm. at (6 V) 65 kg. cm. at (7.4 V) 70 kg. cm. at (8.4 V). Current consumption when stopped (when blocked): 3.5 A/6 V, 5 A/7.4 V, 6.2 mA/8.4 V. Control specification: Control: PWM (pulse width modification). Pulse width range: 500 ~ 2500 μsec. Neutral position: 1500 μsec. Running level: 180° or 270° (at 500~2500 μsec). Dead zone width: 3μsec. Operating frequency: 50-330 Hz. Rotation direction: counter-clockwise (at 500 ~ 2500 μsec). Features: - Durable metal gearbox. - Double ball bearing. - Programmable digital amplifier with Mosft Drive. - Axial mounting hole on the bottom. - Original factory product. - Less noise. - Contains: Long bracket aluminium & short bracket aluminium & circle holder – 18T & circle holder – orientation angle: maximum 180 or 270 deg. - Mechanical angle: 360 degrees (plug/output wheel/radio control system compatible with Futaba JR Hitec).
- How to connect the cable: red is positive, black/brown is negative, white/yellow is signal
- The operating voltage is DC6-8.4V, the best operating voltage is 7.4V. Torque: 58kg.cm.(6v) 65kg.cm.(7.4v) 70kg.cm.(8.4v)
- High quality: metal gear and housing made of aluminium alloy, waterproof IP67 supports wet environment, but cannot be used directly under water
- Control angle 180/270 degrees, 60 kg large torque, supports your DIY project, widely used in robots, robot arms, Baja cars and remote controlled toys
- You will receive 1 PCS 60 kg servo with U-shaped holder disc and accessories
| Brand Name | Wishiot |
|---|---|
| Item Weight | 163 Grams |
| Bearing Type | Ball Bearing |
| Manufacturer | Wishiot |
| Bore Diameter | 5 Millimeters |
| Material Type | Metal |
| Bearing Number | RDS5160 |
| Item Thickness | 5 Millimeters |
| Item Type Name | servo |
| Item Dimensions | 0.2 x 0.12 x 0.39 inches |
| Outside Diameter | 65 Millimeters |
| Specification Met | Ip67 |
| Included Components | Accessories |
| Compatible Lubricant | Grease |
